F Series Truck lsuzu
Isuzu FVR GIGA 5x 18-ton chassis is a heavy-duty commercial vehicle chassis designed for applications that require high load-bearing capacity and stable performance. It is an 18-ton giant that combines powerful power, robust structure and excellent performance. It ensures excellent stability and reliability even under complex road conditions. It is a new benchmark in the field of special vehicles and leads the development trend of the industry.
| Work capacity: | 10～16 tons |
| Engine power: | 240HP |
| Engine type: | 6HK1-TCG61 |
| Axle drive: | 4X2,LHD |
| Gear box: | FAST 8-speed,manual |
| Remarks: | New Isuzu FVR GIGA 5X cabin chassis |
PRODUCT DETAILS
New ISUZU FVR GIGA 5X cabin chassis truck 18tons also called Isuzu FVR GIGA 5X class 240HP chassis,Isuzu FVR GIGA 4x2 18tons chassis,Isuzu new FVR GIGA 5X cab chassis,Isuzu FVR medium chassis with 6HK1 engine, Isuzu FVR GIGA 5x 18-ton chassis.
The New ISUZU FVR GIGA 5X cabin chassis truck 18tons is a heavy-duty commercial vehicle chassis designed for applications that require high load capacity and stability. It uses advanced chassis technology and a sturdy construction to ensure excellent stability and reliability even in complex road conditions. The ISUZU FVR GIGA 5x 18-ton chassis has a powerful power system and optimized axle load distribution, which can easily cope with heavy-duty transportation tasks. At the same time, its flexible configuration options allow manufacturers to customize cargo boxes or vans according to customer needs to meet the transportation needs of different industries.
| New ISUZU FVR GIGA 5X cabin chassis truck 18tons | ||
| Vehicle Dimensions and Parameters | Overall Dimension | 8800*2500*2810 (mm) |
| Wheelbase | 4500mm | |
| Front/ Rear Wheel Distance | 2060/1855mm | |
| Front/Rear Suspension | 1370/2830mm | |
| Weights and Capacities | Curb Weight | 6150 (kg) |
| GVW | 18000kg | |
| Axel Loads | 6500/11500kg | |
| Engine | Model | 6HK1-TCG61 |
| Power | 240HP/175Kw | |
| Displacement | 7790ml | |
| Exhaust Gas Treatment Technology | DPF+SCR | |
| Transmission | FAST 8-speed,manual | |
| Cab | Number of Seats | 2 seats and a bed |
| Chassis | Drive Type | 4x2 |
| Drive speed | 105 Km/h | |
| Tires | 7(Including Spare Tire) | |
| Tire model | 295/80R 22.5 | |
| Fuel Tank | Capacity | 200L |
| Type | Diesel | |
| Configurations | Power Steering System | |
| Air Conditioner | ||
| Retro-reflective Marking | ||
| ABS | ||
| Free Maintenance Battery | ||
With a powerful 18-tonne payload capacity, the new ISUZU FVR GIGA 5X cab-chassis truck is the pinnacle of innovation and performance in the commercial trucking industry. It represents the perfect blend of power, efficiency and reliability, and embodies the essence of modern transport technology. With its cutting-edge design, rugged structure and advanced features, the FVR GIGA 5X sets a new standard for heavy-duty vehicles and promises to revolutionize the way goods are transported.
